Application	Pole-mounted / monitor / kick-back	Pole-mounted / monitor / kick-back
Transducers	8” woofer, ferrite magnet 1” titanium dome, neodymium magnet, ferrofluid cooled	12” woofer, ferrite magnet 1” compression driver, neodymium magnet, ferrofluid cooled
Power rating (peak)	400W	400 W
SPL max1	121 dB	126 dB
Coverage (H x V)	100° x 100°	100° x 60°
Frequency range (-10 dB)2 / response (-3 dB)3	50 Hz – 20 kHz / 60 Hz – 20 kHz	45 Hz – 20 kHz / 55 Hz – 20 kHz
Material	Enclosure: polypropylene Grille: steel with powder coat	Enclosure: polypropylene Grille: steel with powder coat
Digital signal processing	QuickSmartDSP features best-in-class processing powered by Dynacord. Easy setup via seven-band GEQ for main EQ, user-programmable presets, visual monitoring of limiter status, input level control and meters, digital effect control, and master volume control to optimize gain structure, all via LCD or the free QuickSmart Mobile app.
Remote control and monitoring	EV QuickSmart Mobile application: quickly and wirelessly configure, control and monitor up to six EVERSE 8 systems simultaneously, and receive immediate notification during critical performance conditions.	EV QuickSmart Mobile application: quickly and wirelessly configure, control and monitor up to six EVERSE 12 systems simultaneously, and receive immediate notification during critical performance conditions.
Bluetooth audio streaming and true wireless stereo4	YES	YES
Crossover frequency	2250 Hz	2000 Hz
Connectors	2x XLR/TRS combo jack 1x charge port 1x XLR output 1x 12 V DC power output 1x 3.5mm stereo 1x TRS footswitch
USB charging	1.5 A max, device-dependent	1.5 A max, device-dependent
Power consumption5	100 - 240 V~, 50 - 60 Hz, 0.8 - 0.6 A	100 - 240 V~, 50 - 60 Hz, 1.2 - 0.6 A
Battery capacity	86.4 Wh	86.4 Wh
Battery at max output6	6+ hours of run optimize6+ hours of run time	6+ hours of run optimize6+ hours of run time
Battery at moderate output7	12+ hours of run time	12+ hours of run time
Weight	7.6 kg (16.6 lbs)	14.16 kg (31.22 lbs)
Dimensions (W x H x D)	400 mm x 275w mm x 272 mm (15.75” x 10.83” x 10.71”)	345 mm x 597 mm x 347 mm (13.58" x 23.5" x 13.66")
Kick-back / monitor angles	30° / 55°	25° / 55°
Colors	Black and white	Black and white
Accessories	EVERSE8-TRAY-B mic receiver tray black EVERSE8-TRAY-W mic receiver tray white EVERSE-BAT-B battery pack black EVERSE-BAT-W battery pack white EVERSE8-TOTE tote bag EVERSE-DUFFEL padded duffel bag EVERSE8-RAINCVR rain cover	EVERSE12-TRAY-B mic receiver tray black EVERSE8-TRAY-W mic receiver tray white EVERSE-BAT-W battery pack white EVERSE-BAT-B battery pack black EVERSE-DUFFEL padded duffel bag EVERSE12-RAINCVR rain cover

EV QuickSmart Mobile available in select countries. Apple, the Apple logo, iPhone®, iPad®, and App Store® are trademarks of Apple Inc., registered in the U.S. and other countries. Google Play and the Google Play logo are trademarks of Google LLC. EVERSE 8 and EVERSE 12 is available in select countries.
1 Maximum SPL is measured at 1 m using broadband pink noise at maximum output.
2 Half-space measurement.
3 Full space measurement using music DSP preset.
4 Two EVERSE 8 or EVERSE 12 loudspeakers are required for true wireless stereo via a Bluetooth® connection. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Bosch Security Systems, LLC is under license.
5 Current rating is 1/8 power.
6 Maximum output before loudspeaker limit indication, with typical program material.
7 Moderate output is approximately 95 db SPL for EVERSE 8 with typical program material. Moderate output is approximately 100 dB SPL for EVERSE 12 with typical program material. Note powering external devices via the DC power jack, USB connection, and/or phantom power will reduce battery run time.
